DAMCOS BRCF 16000 B1 single-acting balanced rotary actuator 160N4184
DAMCOS BRCF 16000 B1 single-acting balanced rotary actuator 160N4184
The DAMCOS BRCF 16000 B1 is a high-torque hydraulic single-acting balanced rotary actuator designed for marine, offshore, industrial, and ESA-approved valve control applications. It delivers exceptional torque for large valves, using hydraulic pressure to open via port B and fail-safe spring return to close, ensuring safety even in critical offshore or shipboard operations.
This BRCF 16000 B1 actuator is part of Emerson Damcos VRC systems, widely trusted for ball valves, butterfly valves, and plug valves. Its helical spline balanced rotary design ensures smooth 90° rotation while minimizing side forces on valve stems. Built for harsh marine environments, it withstands vibration, saltwater, extreme temperatures, and heavy-duty industrial use.
Big strong robot for giant valves. Turns 90° safely and springs back if needed. Works on ships, offshore platforms, and factories to open and close big valves easily.
Key Specifications:
• Type: BRCF 16000 B1, single-acting, fail-close actuator
• Part Number: 160N4184 (variants: 160N5003)
• Test Pressure: 250 BAR | Working Pressure: 30–135 BAR | Burst Test: 675 BAR
• Torque: 16,000 Nm hydraulic | 8,000 Nm spring return (high torque, heavy-duty actuator)
• Weight: Approx. 467 kg dry (including mounting set)
• Oil Displacement: 3.1 liters
• Temperature Range: -25°C to +80°C
• Rotation: 90° ±1° | Helical spline balanced rotary mechanism
• Valve Shaft Compatibility: DIN 6885 / DIN 79 standards (supports heavy-duty shafts)
Applications
• Marine valve control, ship repair, ship management, offshore platforms
• Ball valves, butterfly valves, plug valves, quarter-turn valves
• Industrial process valves, oil & gas valves, chemical plant valves
• High-demand valve automation, fail-safe actuator systems
• Emerson Damcos VRC integration, ESA-approved actuator
• Heavy-duty hydraulic actuator, balanced rotary actuator, high torque actuator
Product Features :
• Fail-safe spring return: automatically closes valves in emergencies
• High torque hydraulic operation: 16,000 Nm for large valves
• Balanced rotary design: minimizes side forces on valve stems
• Helical spline mechanism: smooth rotation and precise positioning
• Compact and robust: handles harsh marine, offshore, and industrial environments
• Wide temperature range: -25°C to +80°C for extreme conditions
• DIN standard compatibility: easy mounting on existing valve shafts
• ESA-approved: ideal for marine, offshore, and industrial certified systems
