REXROTH DB 20-2-52/315 PRESSURE RELIEF VALVE PILOT OPERATED R900590618
REXROTH DB 20-2-52/315 PRESSURE RELIEF VALVE PILOT OPERATED R900590618
REXROTH PRESSURE RELIEF VALVE PILOT OPERATED
Type : DB 20-2-52/315
MNR : R900590618
124 324 931
FD : 45606
Manufacturer: REXROTH
Type: Pressure Relief Valve Pilot Operated
Model: DB 20-2-52/315 B
Size: 20
Pressure Setting: 315 bar
Ambient Temperature Range: –30 …. +80 oC
Maximum Operating Pressure at Ports P,X :350 bar
Maximum Operating Pressure at Port T :315 bar
Maximum Backpressure at Port Y :315 bar
Maximum Flow Rate: 500 l/min
Hydraulic Fluid Temperature Range: –30 …. +80 oC
Viscosity Range: 10 … 800 mm2/s
